Range Hood & Upper Cabinet Planning: Burlington, Hamilton & Waterdown Guide

Plan the range hood and surrounding upper cabinets as one system. The hood width, installation height, duct route and manufacturer clearances can all affect cabinet widths and placement. For Burlington, Hamilton and Waterdown kitchens, confirm the appliance specification before finalizing the upper-cabinet order.

Why the hood changes the cabinet plan

A hood occupies wall space that might otherwise contain cabinetry. It can also require ducting through an upper cabinet, wall or ceiling. The correct cabinet arrangement depends on the actual hood type and its installation instructions—not on a generic drawing.

Start with the selected cooking appliance

Record the range or cooktop width and exact location. Then use the hood manufacturer's instructions to establish the required hood dimensions and clearances. Do not assume that two appliances with the same nominal width have identical installation requirements.

Choose the hood type before ordering uppers

A chimney-style hood, under-cabinet hood, insert and over-the-range microwave create different cabinet conditions. An under-cabinet unit needs cabinetry above it; a chimney hood may create an intentional open zone; an insert may be integrated into a purpose-built surround. Cabinetry should follow the selected equipment.

Keep the upper run visually intentional

Once the hood opening is established, plan the cabinets on both sides. Wider cabinets can reduce visual fragmentation when the available wall allows it, while narrower units may be needed near corners or windows. Review the available wall cabinet collection and choose sizes only after the hood zone is fixed.

Coordinate upper cabinet height

The surrounding wall cabinets may be 30, 36 or 42 inches tall depending on ceiling height and the overall design. The cabinet directly above an under-cabinet hood can require a different configuration. Use the upper cabinet height guide to understand the broader ceiling relationship.

Account for ducting early

Determine whether the hood is ducted and where the duct travels. A cabinet that looks correct on elevation may lose usable interior space if ductwork must pass through it. Existing framing, exterior-wall conditions and mechanical requirements can also affect the route, so installation details should be confirmed by the appropriate trade.

Watch nearby corners and fillers

Do not push a cabinet door tight against an adjacent wall merely to centre the hood. Cabinet doors and hardware need operating clearance. Fillers can provide adjustment space where required, and the article on fillers, panels and scribes explains their purpose.

Plan electrical and mechanical work around the final design

Cabinet drawings and appliance specifications should be coordinated before rough-in work is treated as final. Moving a hood centre after cabinetry is ordered can affect multiple cabinets. For renovations, verify existing conditions rather than assuming the previous hood location is automatically suitable for the new layout.

Common hood-planning mistakes

• Ordering upper cabinets before selecting the hood type.
• Using nominal appliance dimensions instead of manufacturer specifications.
• Ignoring duct routing through or above cabinetry.
• Centred-looking drawings that do not provide door clearance at a wall.
• Changing the range position after the cabinet list is finalized.
• Assuming hood installation height without checking instructions.

FAQ

Should the range hood be planned before cabinets?

Yes. The selected hood and cooking appliance can determine the opening, cabinet arrangement and ducting conditions.

Can a hood duct run through a cabinet?

Some designs route ducting through cabinetry, but the specific hood instructions and installation conditions determine what is appropriate.

Do I need a cabinet above every range hood?

No. Hood types vary. Some mount below cabinetry, while chimney-style designs can occupy an open wall zone.

Should upper cabinets on both sides be symmetrical?

Symmetry can be visually useful, but functional constraints such as corners, windows and available wall length come first.

What measurements should Burlington homeowners verify?

Confirm wall length, range location and width, ceiling height, selected hood specifications, nearby openings and the proposed duct route before finalizing cabinetry.

Planning principle: fix the cooking and ventilation zone first, then solve the cabinetry around it. That sequence reduces last-minute compromises and produces a cleaner cabinet elevation.
